The list below is of specific equipment on the Polytechnic campus that our group has access to and in some cases, directly manages. In addition to this list, ASU encourages and enables sharing of resources across all of its campuses – so if a piece of equipment you need is not available here, you may find it at this link: https://sharedresources.asu.edu/
Additive Manufacturing
|
Laser Metal 3D Printing
- Concept Laser M2 Cusing
- Concept Laser MLab R Cusing
|
|
Selective Laser Sintering
|
|
Fused Deposition Modeling
- Stratasys Fortus 450mc
- Stratasys Fortus 250mc
- Stratasys Dimension and uPrints
- Several desktop machines
|
|
Composite 3D Printing
|
|
Material Jetting
- Stratasys PolyJet Connex 350
- Stratasys PolyJet Objet 30
|
|
Stereolithography
|
|
Hyrel 3D 30M Modular 3D Printer
- Hot head (filament extrusion), and two syringe heads
- Enclosure with heater for envelope temperature up to 55 deg. C
|
|
Ultimaker S5 Pro Bundle
- Dual extrusion
- Air handler, and Material Handling Station for up to 6 materials
|
Mechanical Testing
|
INSTRON 5985 (Electromechanical) – installed June 2019
- Load Capacity: 250kN
- Primary use: Metals testing
- Advanced Video Extensometer
- Furnace (max rated specimen temp: 1652 F) and high temp extensometers
|
|
INSTRON 8801 Fatigue Tester (Servohydraulic)
- Load Capacity: 50kN
- Primary use: Fatigue
- Also used for low-to-intermediate strain rate compression of cellular materials
|
Characterization
|
3D Digital Image Correlation (DIC) – Aramis (Trilion)
- 12 Megapixel camera pair, frame rate upto 25 Hz at full resolution
- Specimen size 50-350mm
- Blue LED illumination
- GOM Correlate software
|
|
Blue Light 3D Scanner: Zeiss Comet L3D 5M
- 3 different lenses
- Colin3D and Geomagic ControlX software
|
|
Keyence VR-3200 Optical Scanning Microscope
- Dimensional measurements
- Measurement accuracy ±2 to ±5µm
- Automated stage and stitching function
- Primary use: measuring surface roughness and dimensions on manufactured, and biological specimens
|
|
Porosity Measurement Kit with Cole Palmer HR-250A Galaxy Analytical Balance
- 0.1 mg precision, externally calibrated
- Max weight: 252 gm
- Primary use: metal additive manufacturing porosity measurement
|
|
Precision Granite Table
|
Computation
|
Dell Precision 7865 Tower Simulation Workstation
- AMD Ryzen Threadripper PRO 5975WX (128 MB cache, 32 cores, 64 threads, 3.6 GHz to 4.5 GHz)
- Dual NVIDIA RTX A4000, 16 GB GDDR6, 4 DP
|
|
Grasshopper with Rhino 7
- Parametric bio-inspired design
- Response surface generation and analysis with LunchBoxML
|
|
ANSYS
- Topology Optimization
- Geometry repair (SpaceClaim)
- FEA
- HPC Cluster support
|
|
nTopology Platform
- Cellular Material Design and Optimization
|
|
ABAQUS
|
